| Specifications |
|
|
|
|
| Performance |
| Sequential Read Speed* |
Up to 3,400 MB/s |
|
|
|
| Sequential Write Speed* |
Up to 1,700 MB/s |
|
|
|
| Random Read Speed* |
Up to 300,000 IOPS |
|
|
|
| Random Write Speed* |
Up to 300,000 IOPS |
|
|
|
| Specification |
| Capacity |
256 GB |
|
|
|
| Cache |
512 MB LPDDR3L |
|
|
|
| Controller |
Marvell 88SS1092 |
|
|
|
| NAND Flash |
KIOXIA BiCS4 3D TLC |
|
|
|
| Temperature |
|
|
|
|
| Power Requirement |
|
|
|
|
| MTBF |
|
|
|
|
| Endurance (TBW) |
|
|
|
|
| Warranty |
|
|
|
|
| Environment and Reliability |
| Power Requirement |
DC 12V 1.0A (Max.) at PCIe® Slot |
|
|
|
| Temperature |
0℃ ~70℃ / 32℉ ~ 158℉ (Operating) |
|
|
|
| MTBF |
>2,500,000 Hours |
|
|
|
| Endurance (TBW) |
160 |
|
|
|
| Warranty |
5-Year Limited Warranty or 160 TBW Limited Warranty |
|
|
|
| Capacity |
|
|
|
|
| Cache |
|
|
|
|
| Controller |
|
|
|
|
| NAND Flash |
|
|
|
|
| Compatibility |
| Operating System Supported |
Microsoft Windows 8.1, 10/ Linux OS |
|
|
|
| Agency Approval |
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL |
|
|
|
| Command Set Support |
TRIM, S.M.A.R.T, IO queue, NVMe™ command |
|
|
|
| Interface |
M.2 PCIe® Gen 3 x 4 with NVM Express |
|
|
|
| Firmware Upgrade |
Supported |
|
|
|
| Form Factor and Connectors |
| Form Factor |
Standardized PCI Express Card with Half-Height/Half-Length |
|
|
|
| Power Connector |
DC 12V PCI Express Slot |
|
|
|
| Data Connector |
PCI Express Slot |
|
|
|
| Dimension and Weight |
| Dimension (L x W x H) |
176.33 x 121.04 x 22.39 mm / 6.94 x 4.77 x 0.88 inch |
|
|
|
| Weight |
200g / 7.05oz |
|
|
|
| Package Content |
| Drive |
256GB / 512GB / 1TB SSD |
|
|
|
| Accessory |
Half-Height Bracket |
|
|
|
| Document |
Quick Installation Guide |
|
|
|
