COMPARISON

Specifications
Performance
Sequential Read Speed* Up to 3,400 MB/s
Sequential Write Speed* Up to 1,700 MB/s
Random Read Speed* Up to 300,000 IOPS
Random Write Speed* Up to 300,000 IOPS
Specification
Capacity 256 GB
Cache 512 MB LPDDR3L
Controller Marvell 88SS1092
NAND Flash KIOXIA BiCS4 3D TLC
Environment and Reliability
Power Requirement DC 3.3V 2.5A (Max.)
Temperature 0℃ ~70℃ / 32℉ ~ 158℉ (Operating)
MTBF >2,500,000 Hours
Endurance (TBW) 160
Warranty 5 years
Compatibility
Operating System Supported Microsoft Windows 8.1, 10/ Linux OS
Agency Approval UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
Command Set Support TRIM, S.M.A.R.T, IO queue, NVMe command
Interface M.2 PCIe Gen 3 x 4 with NVM Express
Firmware Upgrade Supported
Form Factor and Connectors
Form Factor M.2 2280
Power Connector M.2 connector for DC 3.3V input
Data Connector M.2 Connector
Dimension and Weight
Dimension (L x W x H) 80.00 x 22.86 x 9.20 mm / 3.15 x 0.90 x 0.37 inch
Weight 30.8g / 1.09oz (Max.)
Package Content
Drive 256GB / 512GB / 1TB SSD
Document Quick Installation Guide
