| Specifications |
|
|
|
|
| Performance |
| Sequential Read Speed (MB/s)* |
Up to 560 MB/s |
|
|
|
| Sequential Write Speed (MB/s)* |
Up to 420 MB/s |
|
|
|
| Random Read Speed (IOPS)* |
Up to 65,000 IOPS |
|
|
|
| Random Write Speed (IOPS)* |
Up to 64,000 IOPS |
|
|
|
| Environment and Reliability |
| Power Requirement |
5V / 1.0A (Max.) |
|
|
|
| Operating Temperature |
0 °C~70°C/32°F~158°F |
|
|
|
| Shock Resistance |
1500G(Max.), at 0.5 msec half-sine |
|
|
|
| Vibration Resistance |
2,500,000 Hours |
|
|
|
| MTBF |
2～500Hz, 3.1Grms(Operating) |
|
|
|
| Endurance (TBW) |
70 |
|
|
|
| Warranty |
3-Year Limited Warranty or 70 TBW Limited Warranty |
|
|
|
| Compatibility |
| Operating System Supported |
Microsoft Windows 8.1, 10/ Linux OS |
|
|
|
| Agency Approval |
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL |
|
|
|
| Command Set Support |
TRIM, S.M.A.R.T, IO queue, NVMe command |
|
|
|
| Interface |
SATA 6Gb/s, compatible with SATA 3Gb/s and 1.5 Gb/s |
|
|
|
| Firmware Upgrade |
Supported |
|
|
|
| Form Factor and Connectors |
| Form Factor |
M.2 2280 |
|
|
|
| Power Connector |
M.2 connector for DC 3.3V input |
|
|
|
| Data Connector |
M.2 Connector |
|
|
|
| Dimension and Weight |
| Dimension (L/W/H) |
80.00 x 22.00 x 2.30mm / 3.15 x 0.87 x 0.09 inch |
|
|
|
| Weight (Max.) |
10g / 0.35oz(Max.) |
|
|
|
| Package Contents |
| Drive |
128GB / 256GB / 512GB / 1TB SSD |
|
|
|
