| Specifications |
|
|
|
|
| Performance |
| Sequential Read Speed* |
Up to 560 MB/s |
|
|
|
| Sequential Write Speed* |
Up to 400 MB/s |
|
|
|
| Random Read Speed* |
Up to 60,000 IOPS |
|
|
|
| Random Write Speed* |
Up to 70,000 IOPS |
|
|
|
| Environment and Reliability |
| Power Requirement |
3.3V / 2.0A (Max.) |
|
|
|
| Temperature |
0°C ~ 70°C / 32°F ~ 158°F (Operating) |
|
|
|
| Shock |
1500G (Max.) , at 1 msec half-sine |
|
|
|
| MTBF |
>2,500,000 Hours |
|
|
|
| Endurance (TBW) |
70 |
|
|
|
| Warranty |
3 years |
|
|
|
| Compatibility |
| Operating System Supported |
Microsoft Windows 7, 8.1, 10/ Linux OS |
|
|
|
| Agency Approval |
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL |
|
|
|
| Command Set Support |
TRIM, S.M.A.R.T., NCQ, ATA/ATAPI-8 |
|
|
|
| Interface |
SATA 6Gb/s, compatible with SATA 3Gb/s and 1.5 Gb/s |
|
|
|
| Firmware Upgrade |
Supported |
|
|
|
| Form Factor and Connectors |
| Form Factor |
M.2 2280 |
|
|
|
| Power Connector |
M.2 connector for DC 3.3V input |
|
|
|
| Data Connector |
M.2 connector |
|
|
|
| Dimension and Weight |
| Dimension (L/W/H) |
80.00 x 22.00 x 2.30 mm / 3.15 x 0.87 x 0.09 inch |
|
|
|
| Weight (Max.) |
10g / 0.35oz (Max.) |
|
|
|
| Package Contents |
| Drive |
128GB / 256GB / 512GB SSD |
|
|
|
