| Specifications |
|
|
|
|
| Performance |
| Sequential Read Speed* |
Up to 7,000 MB/s |
|
|
|
| Sequential Write Speed* |
Up to 4,000 MB/s |
|
|
|
| Random Read Speed* |
Up to 650,000 IOPS |
|
|
|
| Random Write Speed* |
Up to 530,000 IOPS |
|
|
|
| Environment and Reliability |
| Power Requirement |
DC 3.3V 2.9A (Max.) |
|
|
|
| Temperature |
0 °C~70°C / 32°F~158°F (Operating) |
|
|
|
| MTBF |
>2,500,000 Hours |
|
|
|
| Warranty |
5-Year Limited Warranty or 320 TBW Limited Warranty |
|
|
|
| Compatibility |
| Operating System Supported |
Microsoft Windows 8.1, 10/ Linux OS |
|
|
|
| Agency Approval |
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS |
|
|
|
| Command Set Support |
TRIM, S.M.A.R.T, IO queue, NVMe™ command |
|
|
|
| Interface |
M.2 PCIe® Gen 4 x 4 with NVMe™ Express |
|
|
|
| Firmware Upgrade |
Supported |
|
|
|
| Form Factor |
M.2 2280 |
|
|
|
| Dimension and Weight |
| Dimension (L/W/H) |
80.0 x 24.0 x 20.5 mm/3.15 x 0.94 x 0.12 inch |
|
|
|
| Weight (Max.) |
50g/1.76oz |
|
|
|
| Package Contents |
| Drive |
512GB / 1TB / 2TB SSD |
|
|
|
| Documents |
Quick Installation Guide |
|
|
|
