COMPARISON

Specifications
Performance
Sequential Read Speed* Up to 3,000 MB/s
Sequential Write Speed* Up to 1,000 MB/s
Random Read Speed* Up to 180,000 IOPS
Random Write Speed* Up to 160,000 IOPS
Environment and Reliability
Power Requirement DC 3.3V 2.5A (Max.)
Temperature 0°C ~ 70°C / 32°F ~ 158°F (Operating)
MTBF >1,500,000 Hours
Endurance (TBW) 160
Warranty 5 years
Compatibility
Operating System Supported Microsoft Windows 8.1, 10/ Linux OS
Agency Approval UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
Command Set Support TRIM, S.M.A.R.T, IO queue, NVMe command
Interface M.2 PCIe Gen 3 x4 with NVM Express
Firmware Upgrade Supported
Form Factor and Connectors
Form Factor M.2 2280
Power Connector M.2 connector for DC 3.3V input
Data Connector M.2 Connector
Dimension and Weight
Dimension (L/W/H) 80.00 x 22.80 x 4.70 mm / 3.15 x 0.90 x 0.19 inch
Weight (Max.) 13g / 0.46oz
Package Contents
Drive 256GB / 512GB / 1TB SSD
