COMPARISON

Specifications
Performance
Sequential Read Speed* Up to 560 MB/s
Sequential Write Speed* Up to 400 MB/s
Random Read Speed* Up to 60,000 IOPS
Random Write Speed* Up to 70,000 IOPS
Environment and Reliability
Power Requirement 5V / 1.0A (Max.)
Temperature 0°C ~ 70°C / 32°F ~ 158°F (Operating)
Shock 1500G (Max.) , at 1 msec half-sine
MTBF >1,500,000 Hours
Endurance (TBW) 70
Warranty 3 years
Compatibility
Operating System Supported Microsoft Windows 8.1, 10/ Linux OS
Agency Approval UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL
Command Set Support TRIM, S.M.A.R.T, IO queue, NVMe command
Interface SATA 6Gb/s, compatible with SATA 3Gb/s and 1.5 Gb/s
Firmware Upgrade Supported
Form Factor and Connectors
Form Factor 2.5 inch
Power Connector 15-pin SATA connector for DC 5V input
Data Connector 7-pin SATA connector
Dimension and Weight
Dimension (L/W/H) 100.00 x 69.85 x 6.80 mm / 3.94 x 2.75 x 0.27 inch
Weight (Max.) 60g / 2.12oz (Max.)
Package Contents
Drive 128GB / 256GB / 512GB SSD
Documents Quick Installation Guide
